Page 105
3120763
4-27
SECTION 4
PLATFORM
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
204
3422723
Rollpin 1/8” x 7/8”
2
205
4160078
Spring
1
206
0361912
Bar, Latch
1
207
2940061
Lat ch Weldment
1
208
0901830
Bracket, Latch
2
PLATFORM EXTENSION LOCK INSTALLATION
OPTIONS:
Ref.
See Note
Standard (S/N 0200104330 to S/N 0200108196)
Ref.
0258101
Standard (S/N 0200108196 to Present)
Ref.
See Note
CSA (S/N 0200104330 to S/N 0200108196)
Ref.
0258102
CSA (S/N 0200108196 to Present)
Ref.
Note: No exact S/N break exists for Lock Mecha-
nism. S/N 0200104330 to S/N 0200108196 installa-
tions could be built with either configuration (See
items 201-208)
Ref.
301
3422950
Pin, 5/16” Rue Ring Stainless
2
302
0641507
Bolt 5/16”-18NC x 7/8”
2
303
3573073
Plate, Foot Latch Rollout
1
304
3422949
Pin, Step Plunger Assembly
1
305
0902750
Bracket, Latch Weldment
1
306
0901830
Bracket, Extension Latch
2
307
4740513
Washer-spec, 1/4-20NC Stainless
1
308
3430406
Pin, 1/4” x 3/4”
1
FIGURE 4-5. HANDRAILS AND EXTENSION INSTALLATION - FOLDDOWN HANDRAILS
(MANUALLY OPERATED EXTENSION) (1532E3/1932E3) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
