SECTION 1 FRAME
.
FIGURE 1-1. DRIVE AND STEERING INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0258147
DRIVE AND STEERING INSTALLATION - 1532E3/1932E3 Ref. 9
0258148
DRIVE AND STEERING INSTALLATION - 2033E3 Ref. 8
0258152 DRIVE AND STEERING INSTALLATION - 2033E3
(JAPANESE SPEC) Ref. 9
1 Drive Motor Assembly Options: 2
1532E3/1932E3 Motor Options:
3160270 S/N 0200098156 to Present (See Figure 1-3 for
Breakdown)
3160228
Prior to S/N 0200098156 (Items 1A-1D are the only
Replacement Parts)
2033E3 Motor Options:
3160263 S/N 0200098156 to Present (See Figure 1-4 for
Breakdown)
3160230
Prior to S/N 0200088491 (Items 1A-1E are the only
Replacement Parts)
— — — — — — — — —
3160228 & 3160230 Replacement Components:
1A
7018997
Nut (1 Per Motor p/n 3160228/3160230) 2
1B 7018996 Key (1 Per Motor p/n 3160228/3160230) 2
1C 7021312 Seal, Shaft (Inner) (Not Shown) (1 Per Motor p/n
3160228/3160230) 2
1D
7021317
Seal, Dust (Outer) (Not Shown) (1 Per Motor p/n
3160228/3160230) 2
1E 7016436 Repair Kit for 3160230 Motor (Includes Items 1C, 1D,
& Qty 1 O-Ring) (Not Shown) (1 Per Motor) 2
2 Spindle Options:
4130336
1532E3/1932E3 2
4130329 2033E3 2
4130348 2033E3 (Japanese Spec) 2
3 0641826 Bolt 1/2”-13NC x 3 1/4” 8
4
4740453
Flatwasher 1/2” 10
5 Use 3300450 Nut 1/2”-13NC (Prior to S/N 0200086330) (was P/N 3311801) 8
6 Use 0100019 Loctite (Prior to S/N 02000103431) (was P/N 0100011) A/R
7
3450406
Cotter Pin 1/8” x 1 1/2” 2
8
3300255
Nut, Wheel 10
9 2780216 Hub 2
9A 7012613 Bolt, Wheel (5 Per Hub) 10
10 Steer Cylinder Options: 1
Use 1684226
Prior to S/N 0200070496 (was p/n 1683428)
Use 1684226 S/N 0200070496 to S/N 0200078796 (was p/n 1683841)
Use 1684226 S/N 0200078796 to S/N 0200105071 (was p/n 1683936)
1684226
S/N 0200105071 to Present
11 Tie Rod Options:
3841387 1532E3/1932E3 1
3841379
2033E3 1
12
2160008
Grease Fitting (Prior to S/N 84439 Only) 2
