SECTION 6 - GENERAL ELECTRICAL INFORMATION & SCHEMATICS
6-34 – JLG Lift – 3121325
GGN NC NC
121 LIYYJZ2X1 UL S. OSCILLATING AXLE
ader 1 PNP5 J2/3 Splice4/L
ader 2 X1/I-2 Splice5/L
122 LIYYJZ2X1 UL
ader 1
Splice4/R
ader 2 Splice5/R
123 LIYYJZ2X1 UL
ader 1
Splice4/R
ader 2 Splice5/R
124 UL1569 18ZW 1
125 UL1569 18ZW 2
126 LIYYJZ25X0.75 UL GROUND PANEL
ader 1 X1/1-1 PA
ader 2 X1/2-1 PB
ader 3 X1/3-1 PC
ader 4 X1/4-2 PD
ader 5 X1/5-2 PE
ader 6 X1/6A-2 PF
ader 7 X1/7A-2 PG
ader 8 X1/9-3 PH
ader 9 X1/21B-2 PJ
ader 10 X1/22-2 PK
ader 11 X1/56-2 PL
ader 12 X1/38-4 PM
ader 13 X1/41A-4 PN
ader 14 X1/32A-1 PO
ader 15 X1/30-2 PP
ader 16 X1/42-1 PQ
ader 17 X1/43-1 PR
ader 18 X1/58-2 PS
ader 19 X1/A-1 PS
ader 20 D25/A PT
ader 21 X1/34B-1 PU
ader 22 PV
ader 23 PW
ader 24 PX
GGN
128 LIYYJZ2X1 UL
ader 1
Splice6/R S1/11
ader 2 Splice8/R S1/12
129 UL 1569 18R K VS/Y1 K VS/Y2
Table 6-1. Main Terminal Box Wiring Description
Wire
Number
Type Position 1 Position 2 Label (External Harness)
