SECTION 6 - GENERAL ELECTRICAL INFORMATION & SCHEMATICS
6-30 – JLG Lift – 3121325
ader 3 X1/48-1
ader 4 X1/49-2
GGN
87 LIYYJZ5X0,5 UL OUTRIGGER 1 SWITCH
ader 1 X1/39-1
ader 2 X1/44-2
ader 3 X1/43-2
ader 4 X1/48-2
GGN
88 LIYYJZ2X1 UL DOWN SWITCH
ader 1 X1/32A-2
ader 2 X1/55-1
89 LIYYJZ2X1 UL OSCILLATING AXLE
ader 1 X1/36-2 Splice6/L
ader 2 X1/35-1 Splice7/L
91 LIYYJZ2X1 UL PUMP 1 VALVE
ader 1 X1/11-1 1
ader 2 X1/G-1 2
92 LIYYJZ2X1 UL PUMP 2
ader 1 X1/11-2 1
ader 2 X1/H-1 2
93 LIYYJZ4X0,75 UL TILT SWITCH
ader 1 X1/28-1
ader 2 X1/29-1
ader 3 X1/B-2
GGN
94 LIYYJZ4X0,75 UL DRIVE 2 VALVE
ader 1 KD2/12 1
ader 2 KD2/22 2
ader 3 X1/F-3 PE
GGN
95 LIYYJZ2X1 UL PRESSURE NIVO SWITCH
ader 1 X1/53-1 1
ader 2 X1/54-1 2
96 LIYYJZ2X1 UL HORN
ader 1 X1/25-1
ader 2 X1/G-2
119 LIYYJZ2X1 UL S 8M
ader 1 X1/36-1
ader 2 X1/37-1
97 LIYYJZ5X1 UL MAX HEIGHT SWITCH
ader 1 X1/36-1
Table 6-1. Main Terminal Box Wiring Description
Wire
Number
Type Position 1 Position 2 Label (External Harness)
