remains on, even if the switch resets, until the igni-
tion input X1/1 (15) is recycled.
8. The monitoring system will shut the engine down
(ouput to X1/7 is cut) if one of the following fault
input signals is present for 3 seconds:
a. No frequency on W - X2/10
b. Input on Oil - X2/1
c. Input on Temp - X2/3
9. When there is a 24V output on X2/9 (50f), the engine
speed is increased by energizing the throttle sole-
noid. The circuit card generates this output from a
24V input on X1/3 (Aux2).
Table 5-12. Deutz Engine Control Board
OU
T
Start
S
olenoi
d
Fu
el
S
ol
en
oi
d
Throttle Solenoid (RPM
)
IN X2/7 X2/8 X2/9
Ignition
X1/1
1 1 1
Start X1/2 1
RPM X1/3 1
Oil Pressure Switch (Ground) X2/1 0
Alternator (D+) X2/2
Temperature Switch (Ground) X2/3 0
Air Filter Switch (Ground) X2/4 0
Alternator (W) X2/10 "0"
Glow Time (Ground) or
Vee Belt (Ground
X2/11
Power 24V X2/5 + + +
Ground X2/6 - - -
"0" = Zero frequency
Table 5-13. Deutz Engine
Connector X1
Ignition X1/1
Start X1/2
RPM X1/3
Connector X2
Oil Pressure Switch (Ground) X2/1
Alternator (D+) X2/2
Temperature Switch (Ground) X2/3
Air Filter Switch Ground) X2/4
Power 24V X2/5
Ground X2/6
Start X2/7
Fuel Solenoid X2/8
RPM Solenoid X2/9
Alternator (W) X2/10
Glow Plug (Ground) or
Vee Belt (Ground)
X2/11
Through Line Connector
24V Power (direct to battery)
24V Power Alternator (B+)
Input
Output
