SECTION 6 - GENERAL ELECTRICAL INFORMATION & SCHEMATICS
3121325 – JLG Lift – 6-31
ader 2 X1/37-1
ader 3 X1/30-1
ader 4 D24/A
GGN
98 LIYYJZ2X1 UL LOWERING VALVE
ader 1 X1/32-1B Splice2/L
ader 2 X1/A-2 Splice3/L
112 LIYYJZ2X1 UL
ader 1
1 Splice2/R
ader 2 2 Splice3/R
113 LIYYJZ2X1 UL
ader 1
1 Splice2/R
ader 2 2 Splice3/R
99 LIYYJZ2X1 UL SER/PAR
ader 1 X1/16-1 1
ader 2 X1/F-1 2
111 LIYYJZ2X1 UL DIFF LOCK VALVE 1
ader 1 X1/20-2 1
ader 2 X1/C-2 2
100 LIYYJZ2X1 UL DIFF LOCK VALVE 2
ader 1 X1/20-1 1
ader 2 X1/D-2 2
101 LIYYJZ2X1 UL BRAKE VALVE
ader 1 X1/13A-1 1
ader 2 X1/E-1 2
102 LIYYJZ2X1 UL MAX HEIGHT SWITCH
ader 1 X1/34A-1
ader 2 X1/27-1
103 LIYYJZ7X1 UL ENGINE BOX
ader 1 X1/8-1
ader 2 X1/9-1
ader 3 X1/41A-1
ader 4 X1/58-3
ader 5 X1/I-1
ader 6
GGN
104 LIYYJZ5X1 UL 2,5m SWITCH
ader 1 X1/34A-2
ader 2 X1/26-1
ader 3 X1/35-2
ader 4 X1/36-3
GGN
Table 6-1. Main Terminal Box Wiring Description
Wire
Number
Type Position 1 Position 2 Label (External Harness)
