SECTION 6 - GENERAL ELECTRICAL INFORMATION & SCHEMATICS
3121325 – JLG Lift – 6-29
142 UL1569 18GR D16/A C2 J1B/10
74 UL1569 18GR C2 J1B/11 X1/25-4
75 UL1569 18GR C2 J1B/12 X1/6B-4
76 UL1569 18GR X1 FUSE/B X1/2-4
77 UL1569 18GR X1 FUSE/T X1/3-4
78 UL1569 18GR J8/1 X1/3-3
79 UL1569 18GR J8/9 X1/34B-4
80 UL1569 18GR J8/2 X1/26-2
81 UL1569 18GR J8/6 X1/39-3
82 UL1569 18GR J8/3 X1/40-2
83 UL1569 18GR J8/4 X1/41A-3
128 UL1569 18ZW S1 oscillating/12 S2 oscillating/11
124 UL1569 18ZW 1
125 UL1569 18ZW 2
114 UL1569 18ZW A/2 B/2
115 UL1569 18GR trig contr J2/3 D19/A
138 UL1569 18GR C2 J2B/1 D19/A
130 UL1569 18GR KTC/24 C2 J2B/8
131 UL1569 18GR X1/31-1 D17/A
137 UL1569 18GR K TC/11 D17/K
132 UL1569 18GR KTC/A2 X1/I-4
133 UL1569 18GR KTC/A1 trig contr J2/3
143 UL1569 18GR KL/24 C2 LED/GROEN
144 UL1569 18GR X1/D-3 KL/A2
145 UL1569 18GR X1/38-1 KL/11
146 UL1569 18GR D24/K KL/A1
147 UL1569 18GR D25/K KL/A1
84 LIYYJZ5X0,5 UL OUTRIGGER 4 SWITCH
ader 1 X1/46-1
ader 2 X1/47-1
ader 3 X1/50-1
ader 4 X1/51-1
GGN
85 LIYYJZ5X0,5 UL OUTRIGGER 3 SWITCH
ader 1 X1/45-1
ader 2 X1/46-2
ader 3 X1/49-1
ader 4 X1/50-2
GGN
86 LIYYJZ5X0,5 UL OUTRIGGER 2 SWITCH
ader 1 X1/44-1
ader 2 X1/45-2
Table 6-1. Main Terminal Box Wiring Description
Wire
Number
Type Position 1 Position 2 Label (External Harness)
