SECTION 6 - GENERAL ELECTRICAL INFORMATION & SCHEMATICS
6-32 – JLG Lift – 3121325
105 LIYYJZ4X1 UL PLATFORM VALVE
ader 1 X1/22-1 1
ader 2 X1/21B-1 2
ader 3 X1/H-2 PE
GGN
106 LIYYJZ4X1 UL LIFT VALVE
ader 1 KL/14 1
ader 2 X1/32B-3 2
ader 3 X1/B-1 PE
GGN
107 LIYYJZ4X1 UL DRIVE VALVE
ader 1 X1/13B-1 1
ader 2 X1/14-1 2
ader 3 X1/D-1 PE
GGN
108 LIYYJZ4X1 UL STEERING VALVE
ader 1 X1/18-1 A/1
ader 2 X1/17-1 B/1
ader 3 X1/C-1 A/2
GGN
109 LIYYJZ12X0,75UL OUTRIGGER VALVES
ader 1 J7/1 1 OUTRIGGER 1 VALVE
ader 2 J7/2 2
ader 3 J7/3 PE
ader 4 J7/4 1 OUTRIGGER 2 VALVE
ader 5 J7/5 2
ader 6 J7/6 PE
ader 7 J7/7 1 OUTRIGGER 3 VALVE
ader 8 J7/8 2
ader 9 J7/9 PE
ader 10 J7/10 1 OUTRIGGER 4 VALVE
ader 11 J7/11 2
GGN J7/12 PE
126 LIYYJZ25X0,75UL GROUND PANEL
ader 1 X1/1-1 PA
ader 2 X1/2-1 PB
ader 3 X1/3-1 PC
ader 4 X1/4-2 PD
ader 5 X1/5-2 PE
ader 6 X1/6A-2 PF
ader 7 X1/7B-2 PG
ader 8 X1/9-2 PH
Table 6-1. Main Terminal Box Wiring Description
Wire
Number
Type Position 1 Position 2 Label (External Harness)
