SECTION 6 - GENERAL ELECTRICAL INFORMATION & SCHEMATICS
3121325 – JLG Lift – 6-33
ader 9 X1/21B-2 PJ
ader 10 X1/22-2 PK
ader 11 X1/56-2 PL
ader 12 X1/38-4 PM
ader 13 X1/41B-1 PN
ader 14 X1/32A-1 PO
ader 15 X1/30-2 PP
ader 16 X1/42-1 PQ
ader 17 X1/43-1 PR
ader 18 X1/58-2 PS
ader 19 PT
ader 20 D25/A PU
ader 21 X1/B34-1 PV
ader 22 PW
ader 23 PX
ader 24
GGN
110 LIYYJZ25X1 UL SCISSORS CABLE SOCKET
ader 1 X2/1 C2 J2A/1
ader 2 X2/2 C2 J2A/2
ader 3 X2/3 C2 J2A/3
ader 4 X2/4 C2 J2A/4
ader 5 X2/5 C2 J2A/5
ader 6 X2/6 NC
ader 7 X2/7 NC
ader 8 X2/8 C2 J2A/8
ader 9 X2/9 trig contr J2/2
ader 10 X2/10 C2 J2B/2
ader 11 X2/11 NC
ader 12 X2/12 C2 J2B/4
ader 13 X2/13 C2 J2B/5
ader 14 X2/14 C2 J2B/6
ader 15 X2/15 C2 J2B/7
ader 16 X2/16 KTC/21
ader 17 X2/17 X1/59-1
ader 18 X2/18 C2 LED/GEEL
ader 19 X2/19 KL/21
ader 20 X2/20 C2 LED/BLAUW
ader 21 X2/21 NC
ader 22 X2/22 C2 LED/ZWART
ader 23 X2/23 X1/58-1
ader 24 X2/24 NC
Table 6-1. Main Terminal Box Wiring Description
Wire
Number
Type Position 1 Position 2 Label (External Harness)
