3121112 3-3
SECTION 3 SCISSOR ARMS
S
E
C
T
I
O
N
3
S
C
I
S
S
O
R
A
R
M
S
.
FIGURE 3-1. SCISSOR ARMS INSTALLATION - 330CRT
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0259105 SCISSOR ARMS INSTALLATION - 330CRT Ref. K
1 Not Used
2 0100011 Loctite #242 (Not Shown) A/R
3 0200654 Arm Weldment (Bottom Inboard) 1
4 0200655 Arm Weldment (Lower Mid Inboard) 1
5 0200656 Arm Weldment (Upper Mid Inboard) 1
6 0200657 Arm Weldment (Top Inboard) 1
7 0200658 Arm Weldment (Bottom Left Side Outboard) 1
8 0200659 Arm Weldment (Lower Mid Left Side Outboard) 1
9 0200660 Arm Weldment (Upper Mid Left Side Outboard) 1
10 0200661 Arm Weldment (Top Outboard) 1
11 0200667 Arm Weldment (Bottom Right Side Outboard) 1
12 0200668 Arm Weldment (Lower Mid Right Side Outboard) 1
13 0200669 Arm Weldment (Upper Mid Right Side Outboard) 1
14 0362840 Bar, Cable Carrier 1
15 0362841 Bar, Cable Carrier 1
16 0440234 Bushing A/R
17 0440236 Bushing A/R
18 0641418 Bolt 1/4”-20NC x 2 1/4” 2
19 Not Used
20 0641510 Bolt 5/16”-18NC x 1 1/4” A/R
21 0641608 Bolt 3/8”-16NC x 1” 1
22 0641610 Bolt 3/8”-16NC x 1 1/4” 2
23 0681520 Bolt 5/16”-18NC x 2 1/2” (Grade 8) 2
24 0681622 Bolt 3/8”-16NC x 2 3/4” (Grade 8) 2
25 0681624 Bolt 3/8”-16NC x 3” (Grade 8) 20
26 Not Used
27 0902540 Bracket, Limit Switch 1
28 4740480 Washer, Plastic Insert 4
29 Harness, Limit Switch Options: (See Section 7 for Break-
down) 1
Use 4922630 Prior to S/N 101118 (Was p/n 1060868)
4922630 S/N 101118 to Present
30 Not Used
31 1100110 Cam, Activator 1
32 3450304 Pin, Cotter 4
33 1683858 Lift Cylinder Assembly (See Section 5 for Breakdown) 1
34 3311805 Locknut #8-32NC 2
35 3300151 Nut, Acorn 1/4”-20NC 2
36 3311505 Locknut 5/16”-18NC A/R
37 3311605 Locknut 3/8”-16NC 25
38 Not Used
39 3340856 Pad, Slide 2
40 3340866 Pad, Arm A/R
41 3422369 Pin, Plunger 1
42 3422821 Pin, Pivot 2
43 3422822 Pin, Pivot 2
