2-4 3121112
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
25 3310805 Locknut #8-32NC 4
26 3311505 Locknut 5/16”-18NC 1
27 3900289 Screw, Phillips Head #8-32NC 4
28 3900208 Screw 3/8”-16NC x 1” 1
29 Not Used
30 4750800 Flatwasher #8 4
31 4060808 Flex-Trim 6ft/1.8m
32 3572362 Plate, Cover 1
33 4761500 Lockwasher 5/16” 1
34 0641524 Bolt 5/16”-18NC x 3” 4
35 4568114 Tube, Spacer 4
36 0641405 Bolt 1/4”-20NC x 5/8” 4
37 1780317 Door 1
38 2600147 Hinge, Door 1
39 0641410 Bolt 1/4”-20NC x 1 1/4” 8
ELECTRICAL COMPONENTS INSTALLATIONS Ref.
0259580 Dual Fuel Gas Machines Ref. D
0259583 Diesel Machines Ref. D
0259582 Dual Fuel Gas Machines with Leveling Jacks Ref. B
0259581 Diesel Machines with Leveling Jacks Ref. C
101 0140001 Horn 1
102 Ground Control Box Assembly Options (See Figure
2-4 for Breakdown): 1
0259645 Dual Fuel Gas Machines (Production)
0259864 Dual Fuel Gas Machines (Post Production)
0259829 Diesel Machines (Production)
0270423 Diesel Machines (Post Production)
0259864 Dual Fuel Gas Machines with Leveling Jacks
0270423 Diesel Machines with Leveling Jacks
103 0641404 Bolt 1/4”-20NC x 1/2” A/R
104 0641406 Bolt 1/4”-20NC x 3/4” 4
105 0641506 Bolt 5/16”-18NC x 3/4” 1
106 0902590 Bracket, Ground Control Box 2
107 3311405 Locknut 1/4”-20NC A/R
108 3311505 Locknut 5/16”-18NC 1
109 4751500 Flatwasher 5/16” 2
110 4761400 Lockwasher 1/4” 4
111 Harness, Engine & Valve Options (Not Shown - See
Section 7 for Breakdown): 1
4922343 Machines without Leveling Jacks
4922441 Machines with Leveling Jacks
112 4711400 Flatwasher 1/4” (Narrow) 1
FIGURE 2-1. RIGHT SIDE COMPARTMENT INSTALLATIONS (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
