3121112
8-3
SECTION 8
DECALS
S
E
C
T
I
O
N
8
D
E
C
A
L
S
FIGURE 8-1. DECALS INSTALLATION - ANSI
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
0259598
DECAL INSTALLATION
Ref.
8
1
0641405
Bolt 1/4”-20NC x 5/8”
4
2
0860520
Box, Manual Storage
1
3
1702153
Decal - Inspection
1
4
Not Available
Decal - Bar Code
1
5
Not Used
6
1703816
Decal - Danger/Warning
1
7
1704211
Decal - Safety Prop
1
8
Not Used
9
Use 1701509
Decal - Manual Reference (Was p/n 1703788)
1
10
1703811
Decal - Lifting Lugs
4
11
1703812
Decal - Hydraulic Oil
1
12
1703814
Decal - Tie Down
4
13
1704277
Decal - Attach Lanyard Here
8
14
1703819
Decal - Directional Arrow
1
15
Decal - Manual Descent Options: (Prior to S/N 88958
Only)
1
1703822
330CRT
Not Available
400CRT
16
Not Used
17
1704480
Decal - Legend
1
18
1704556
Decal - Towing/Winching/Tow Speed
1
19
1703696
Decal - Gradeability
1
20
1703818
Decal - Warning Crushing Hazard/Danger Electrocution
4
21
1703821
Decal - Control Box Location
1
22
3251813
Decal - USA
1
23
Not Available
Nameplate - Serial Number
1
24
3311405
Locknut 1/4”-20NC
4
25
4711400
Flatwasher 1/4” Narrow
8
26
1060279
Cable, Lanyard
1
27
1704412
Decal - Hydraulic Oil
1
28
1700584
Decal - Patent
1
29
1704479
Decal - Battery Warning
1
30
2080057
Fastener (Not Shown)
4
31
1703687
Decal - Directional Arrow
1
— — — — — — — — — — — —
Decal Kit Options:
A/R
2901912
Master Kit (Includes Items 9-15)
1
5
2901914
Multi-Color Kit (Includes Items 17-21)
1
OPTIONAL DECAL INSTALLATIONS
Ref.
101
1701214
Decal - Outrigger Warning (Optional - Not Shown)
8
102
1702788
Decal - Biodegradable Oil (Optional)
1
