7-12 3121112
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
302 Harness, Lift Down Options: 1
4922321 330CRT C
4922345 400CRT C
1060680 Cable, Electrical - 18/2 A/R
330CRT 21ft/6.4m
400CRT 45ft/13.7m
302A 4460499 Connector, DIN A/R
330CRT 1
400CRT 2
4460465 Socket, Female 2
303 Elevation Switch Harness Options: 1
Use 4922630 Prior to S/N 101118 (Was p/n 1060868)
4922630 S/N 101118 to Present
1060680 Cable, Electrical - 18/2 9ft/2.75m
303A 4460465 Socket, Female 2
303B Switch, Limit Options: 1
4360321 Production
4360548 Post Production
303C Connector, Strain Relief Options: 1
4460662 Prior to S/N 101118 (Use with 1060868
Harness)
4460428 S/N 101118 to Present (Use with 4922630
Harness) (Production)
4460968 Post Production
304 Not Available Harness, Controller (Part of Electrical Assembly) 1
304A 4460265 Connector - 9 Position 1
4460268 Socket, Female 8
305 Drive Cutout Switch Harness Options: (400CRT Only) 1
Use 4922630 Prior to S/N 101118 (Was p/n 1060869)
4922630 S/N 101118 to Present
1060680 Cable, Electrical - 18/2 11ft/3.4m
305A 4460465 Socket, Female 2
305B Switch, Limit Options: 1
4360321 Production
4360548 Post Production
305C Connector, Strain Relief Options: 1
4460662 Prior to S/N 101118 (Use with 1060869
Harness)
4460428 S/N 101118 to Present (Use with 4922630
Harness) (Production)
4460968 Post Production
OPTIONAL HARNESS COMPONENTS Ref.
401 4922425 Alarm Harness 1 B
1060680 Cable, Electrical - 18/2 7ft/2.2m
401A 4460248 Terminal 2
401B 4460465 Socket, Female 2
401C 0140032 Alarm 1
FIGURE 7-4. ELECTRICAL COMPONENTS INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
