SECTION 1 FRAME
.
FIGURE 1-13. FRAME COVERS AND LADDERS INSTALLATION
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
0259562
ENGINE COVER INSTALLATION
Ref.
C
1
0100019
Loctite #271 (Not Shown)
A/R
2
0641405
Bolt 1/4”-20NC x 5/8”
6
3
1670943
Cover, Engine
1
4
4711400
Flatwasher 1/4” (Narrow)
6
FRAME COVERS INSTALLATION OPTIONS:
Ref.
0259947
Fixed Rear Axle Machines (Prior to S/N 71310)
Ref.
B
0259948
Oscillating & Fixed Rear Axle Machines (S/N 71310 to
Present)
Ref.
C
101
0100011
Loctite #242 (Not Shown)
A/R
102
0641406
Bolt 1/4”-20NC x 3/4”
A/R
103
Bolt Options:
A/R
0641506
Bolt 5/16”-18NC x 3/4” (Fixed Rear Axle - Prior to
S/N 71310)
10
0641405
Bolt 1/4”-20NC x 5/8” (Oscillating/Fixed Rear Axle -
S/N 71310 to Present)
2
0641407
Bolt 1/4”-20NC x 7/8” (Oscillating/Fixed Rear Axle - Use
on Axle Covers) (S/N 71310 to Present)
4
104
Cover, Axle Options:
2
1670933
Fixed Rear Axle (Prior to S/N 71310)
3572029
Oscillating/Fixed Rear Axle (S/N 71310 to Present)
105
1670934
Cover, Frame - Front
1
106
Cover, Frame - Center Options:
1
1670935
Fixed Rear Axle (Prior to S/N 71310)
1670937
Oscillating/Fixed Rear Axle (Not Shown - Items 106 &
107 are 1 piece) (S/N 71310 to Present)
107
Cover, Frame - Rear Options:
1
1670936
Fixed Rear Axle (Prior to S/N 71310)
1670937
Oscillating/Fixed Rear Axle (Not Shown - Items 106 &
107 are 1 piece) (S/N 71310 to Present)
108
2080052
Fastener 1/4”-20NC
A/R
109
Nut Options:
A/R
0641506
Nut 5/16”-18NC (Fixed Rear Axle) (Prior to S/N 71310)
10
0641405
Nut 1/4”-20NC (Oscillating/Fixed Rear Axle) (S/N 71310
to Present)
2
110
4751400
Flatwasher 1/4”
8
111
4751500
Flatwasher 5/16”
A/R
112
4060803
Flex-Trim
4.5in/11cm
