SECTION 1 FRAME
.
FIGURE 1-9. GAS DUAL FUEL ENGINE INSTALLATION - KUBOTA
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0259850 GAS DUAL FUEL ENGINE ASSEMBLY Ref. H
1 0641410 Bolt 1/4”-20NC x 1 1/4” 2
2 0641508 Bolt 5/16”-18NC x 1” 1
3 0641812 Bolt 1/2”-13NC x 1 1/2” 4
4 0641814 Bolt 1/2”-13NC x 1 3/4” 2
5 0760812 Bolt, Metric M8 x 25mm 8
6 0902614 Bracket, Air Cleaner 1
7 0902639 Bracket, Reserve Tank 1
8 0902623 Bracket, Radiator Seal 1
9 1320016 Clamp 4
10 1320274 Clamp, Exhaust 1
11 2000170 Engine, Kubota WG-750 Gas Dual Fuel 1
12 2720458 Hose, Air Intake 1
13 2720459 Hose, Air Intake 1
14 3290801 Nut, Metric M8 4
15 3311405 Locknut 1/4”-20NC 2
16 3311505 Locknut 5/16”-18NC 1
17 3311805 Locknut 1/2”-13NC 6
18 3460314 Pipe, Exhaust 1
19 3460315 Pipe, Exhaust 1
20 Not Used
21 4240143 Strap, Exhaust 1
22 4711400 Flatwasher 1/4” Narrow 4
23 4711500 Flatwasher 5/16” 2
24 4711800 Flatwasher 1/2” Narrow 12
25 4740495 Washer, Special 1
26 4761600 Lockwasher 3/8” 4
27 Not Used
28 4846036 Engine Tray Weldment 1
29 1320265 Clamp, Loop 1
30 0840026 Boot, Terminal (Not Shown - Located at Positive Post of
Alternator) 1
31 2120077 Filter-Lock, LP Gas 1
32 Not Used
0259380 GAS DUAL FUEL ENGINE INSTALLATION Ref. J
100 4400275 Tank, LP 1
101 0100020 Sealant, Pipe (Not Shown) A/R
102 Not Used
103 0400002 Hold-Down, Battery 1
2910479 Clip Repair Kit 1
104 0400003 Battery 1
105 0641418 Bolt 1/4”-20NC x 2 1/4” 4
106 0641612 Bolt 3/8”-16NC x 1 1/2” 4
107 0641632 Bolt 3/8”-16NC x 4” 2
108 0641672 Bolt 3/8”-16NC x 9” 2
