3121112
2-13
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
FIGURE 2-5. FUEL COMPARTMENT INSTALLATION
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
0259560
FUEL TANK INSTALLATION
Ref.
F
1
0100011
Loctite #242 (Not Shown)
A/R
2
0641407
Bolt 1/4”-20NC x 7/8”
4
3
1670931
Cover, Fuel Tank
1
4
2080052
Fastener 1/4”-20NC
4
5
2420191
Gauge/Sender, Fuel Level
1
6
3900128
Screw, Round Head
5
7
4400427
Fuel Tank Assembly
1
See Item 102
Cap, Tank
1
8
4420037
Tape, Padded
52in/1.3m
9
4751000
Flatwasher #10
5
10
4751400
Flatwasher 1/4”
4
11
Not Used
12
3960525
Gasket, Fuel Gauge
1
13
3311601
Nut 3/8”-16NC
2
14
4240139
Strap, Tank Mounting
1
15
4711600
Flatwasher 3/8” (Narrow)
2
FUEL TANK CAP OPTIONS:
Ref.
4400427
Standard Tank Cap
Ref.
D
0259613
Optional Locking Tank Cap
Ref.
B
101
0100020
Sealant, Pipe (Not Shown - Locking Cap only)
A/R
102
Cap Options:
1
7020257
Standard Cap
1120485
Locking Cap
