3121112 2-11
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
FIGURE 2-4. GROUND CONTROL BOX ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
GROUND CONTROL BOX ASSEMBLY OPTIONS: Ref.
0259829 Diesel Machines Ref. K
0270423 Diesel Machines Ref. K
0259645 Dual Fuel Gas Machines (Production) Ref. L
0259864 Dual Fuel Gas Machines (Post Production) Ref. K
0270423 Diesel Machines with Leveling Jacks Ref. K
0259864 Dual Fuel Gas Machines with Leveling Jacks Ref. K
1 Circuit Board Options: 1
0610140 Machines without Leveling Jacks (Production)
0610134 Machines without Leveling Jacks (Post Production)
0610134 Machines with Leveling Jacks
2 0861315 Box Assembly 1
2A Not Available Latch 1
3 Decal Options: 1
1704462 Prior to S/N 112399
1705729 S/N 112399 to Present
4 2420172 Gauge, Hourmeter 1
5 2920026 Holder, Bulb 4
6 2920029 Bulb, Light 4
7 3900281 Screw, Socket Head 8
8 3910606 Screw #6-32NC x 3/8 3
9 3910616 Screw #6-32NC x 1” 4
10 3910804 Screw #8 x 1/4” 3
11 4070987 Shim (.015) 3
12 4070991 Shim (.125) 1
13 4360070 Breaker, Circuit - 15Amp 1
14 4360328 Switch, Toggle 1
15 4360387 Switch, Push Button 2
16 4360469 Switch, Key 1
16A 2860030 Key, Replacement (Set of 2) 1
17 4360475 Switch, Mushroom 1
7020175 Ring, Sealing 1
17A 7020176 Block, Contact 1
18 4360481 Block, Switch - Dual Axis 1
19 4750600 Flatwasher #6 3
20 4760600 Lockwasher #6 4
21 4761000 Lockwasher #10 8
22 Harness, Ground Control Box (Not Shown - See
Section 7 for Breakdown) 1
4922378 Diesel Machines
4922336 Gas/Dual Fuel Machines
23 4922339 Harness, Tilt (Not Shown - See Section 7 for Break-
down) 1
24 3520026 Plug (Dual Fuel Machines Only) 1
25 3520193 Plug (S/N 112399 to Present Only) 1
26 Not Used
27 3520030 Plug, Hole (Post Production) 1
