3121112 1-39
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
.
FIGURE 1-12. FRAME MOUNTED COMPONENTS INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
ALARM INSTALLATIONS (OPTIONAL) Ref.
0259591 Descent Ref. D
0259592 Motion Ref. D
1 Not Used
2 0641508 Bolt 5/16”-18NC x 1” 2
3 Not Used
4 3311505 Locknut 5/16”-18NC 2
5 to 6 Not Used
7 4711500 Flatwasher 5/16” Narrow 2
8 4922425 Harness, Alarm (Not Shown - See Section 7 for
Breakdown) 1
9 Not Used
0259593 BEACON LIGHT INSTALLATION (OPTIONAL) Ref. B
101 to 102 Not Used
103 2820018 Tube, Heat Shrink (Not Shown) A/R
104 2920146 Beacon Light Assembly 1
7016319 Tube, Flash 1
7016372 Lens, Replacement Amber 1
105 3941004 Screw, Self-Tapping #10-24NC x 1/2” 2
106 to 110 Not Used
111 4922426 Harness, Beacon (Not Shown - See Section 7 for Breakdown) 1
