3121112 2-7
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
FIGURE 2-2. MAIN CONTROL VALVE ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
4641157 MAIN CONTROL VALVE ASSEMBLY Ref. D
1 Not Serviced Manifold 1
2 7017410 Cartridge Less Coil (Dump) 1
7012967 Seal Kit - 7017410 Cartridge 1
7012944 Coil 1
3 7017418 Cartridge, Relief (Lift Up) 1
7012998 Seal Kit - 7017418 Cartridge 1
4 7017418 Cartridge, Relief (Main) 1
7012998 Seal Kit - 7017418 Cartridge 1
5A 7021649 Cartridge, Relief (Steer Right) 2
7021651 Seal Kit - 7021649 Cartridge (1 Per Cartridge) 2
5B 7021650 Cartridge, Relief (Steer Left) 2
7021651 Seal Kit - 7021650 Cartridge (1 Per Cartridge) 2
6 7022527 Orifice 1/16”/2.0mm (Not Shown - Located on Back of
Valve at Port L) 1
7 7012941 Cartridge Less Coil (Brake Release) 1
7010543 Seal Kit - 7012941 Cartridge 1
7012944 Coil 1
8 7018901 Valve Assembly 1
7022531 Seal Kit 1
9 7022529 Valve Assembly (Lift) 1
7012773 Seal Kit 1
9A 7021375 Nut 1
9B 7021376 Coil 1
10 7022530 Valve Assembly (Steer) 1
7012773 Seal Kit 2
10A 7021375 Nut 2
10B 7021376 Coil 2
11 7018903 Tube Assembly 1
7018904 Fitting, Straight 1
12 7021646 Cartridge, Check 1
7012998 Seal Kit - 7021646 Cartridge 1
13 7021629 Cartridge, Needle Valve 1
7012953 Seal Kit - 7021629 Cartridge 1
14 7023208 Valve Assembly (Manual Descent) 1
7023209 Seal Kit - 7023208 Cartridge 1
14A 7023210 Handle 1
15 7010542 Cartridge 1
7010543 Seal Kit - 7010542 Cartridge 1
16 7018942 Capscrew, Socket Head #10-24NC x 2” 12
