SECTION 1 FRAME
.
FIGURE 1-15. GENERATOR INSTALLATION - 110V (OPTIONAL)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0259696 GENERATOR INSTALLATION - 110V Ref. A
Note: Mounting Hardware Supplied with Generator
Assembly Ref.
1 1060882 Cable, AC (See Section 7 for Breakdown) 1
2 2460036 110V Generator Assembly (Hydraulic) 1
2A 7023232 Generator Only 1
7023233 Brush Assembly 1
2B 7023235 Motor Assembly Only 1
2C 7010635 Cartridge 1
2900708 Seal Kit - 7010635 Cartridge 1
7012943 Coil 1
2D 7023234 Cartridge 1
2E 7023247 Receptacle (Not Shown) 1
3 Not Used
4 3311401 Nut 1/4-20NC 1
5 3740049 Relay, Skirted 1
6 4060803 Shield, Flex Trim 1ft/.3m
7 4761400 Lockwasher 1/4” 1
8 4922452 Harness, Generator (See Section 7 for Breakdown) 1
