3121112 4-1
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
SECTION 4 PLATFORM
TABLE OF CONTENTS
FIGURE DESCRIPTION PAGE
4-1 PLATFORM AND ACCESSORIES INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4-2 FOLDDOWN HANDRAILS & EXTENSION INSTALLATION (MANUALLY OPERATED
PLATFORM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
4-3 PLATFORM CONSOLE BOX ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
4-4 DRIVE/STEER CONTROLLER ASSEMBLY (PRODUCTION) . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
4-5 DRIVE/STEER CONTROLLER J.R. MERRITT ASSEMBLY (POST PRODUCTION) . . . . . . . . 4-14
