40
Catalog Number Type of Clamp
ACE-6000S 6.0L Erlenmeyer Clamp
ACE-2800S 2800mL Fernbach Flask Clamp
ACSB-500S 500mL Media Bottle Clamp
ACSB-1000S 1.0L Media Bottle Clamp
7.6 Clamp Mounting Hardware
NBS flask clamps are used on a variety of shaker platforms. Flat head screws of
different lengths and thread pitch are used to secure the clamp. The tables below
identify the proper screw for your shaker application by reference to the head style:
7.6.1 Hardware for 10 mL to 500 mL Clamps
Description Part Number Qty. Application
10-24 x 5/8 (15.87 mm)
flat Phillips (+) head screw S2116-3101 1 3/4" (19.05 mm) thick
wood platform
10-24 x 5/16 (7.9 mm) flat
Phillips (+) head screw S2116-3051 1 5/16" (7.9 mm) thick
aluminum, phenolic and
stainless stee
lplatforms.
10-32 x 5/16 (7.9 mm) flat
slotted (-) head screw S2117-3050 1 all stainless steel
platforms
7.6.2 Hardware for 1-Liter to 6-Liter Clamps
Description Part Number Qty. Application
10-24 x 5/8 (15.87 mm)
flat Phillips (+) head
screw S2116-3101 5 3/4" (19.05 mm) thick
wood platform
10-24 x 5/16 (7.9 mm)
flat Phillips (+) head
screw S2116-3051 5 5/16" (7.9 mm) thick
aluminum, phenolic
and stainless steel
platforms.
10-32 x 5/16 (7.9 mm)
flat slotted (-) head screw S2117-3050 5 all stainless steel
platforms

NOTE: 2800 mL Fernbach Flask Clamp applicable to above chart.
