35
Innova 3100  M1231-0050 Operating manual
6 6 S S
P PE EC CIIF FIIC CA AT TIIO ON NS S
This chapter provides technical details of interest, but not necessarily
essential for operation of the instrument.
SHAKING
Speed
25-400 RPM
Motion ½ inch (12.7 mm) diameter circular orbit
Indication LED digital electric display, 1 RPM increments
Setpoint & Control Digital adjustment with PI microprocessor control and
instantaneous visual feedback
Accuracy
± 1 RPM
DRIVE
Triple eccentric counterbalanced ball bearing drive.
TEMPERATURE
Range
5.0
°C above ambient to 80°C
Range with Cooling
Option 5.0
°C above coolant temperature to 80°C
Control Stability
± 0.1°C by use of PI microprocessor controller and pulse width
modulation of heater
Setpoint Digital adjustment increments (0.1
°C increments) with
instantaneous visual feedback
Accuracy
± 0.1° @ 30-40°C range
± 0.50°C for remaining range
Uniformity Better than 0.5
°C
Safety Heater shuts off if temperature exceeds operating range. Two
safeties provided.
Heater Low watt density resistance mat heater
TIMER (Shaker)
• Programmable shaking periods from 0.1 hour to 99.9 hours by a digital timer that shuts
off at the end of period and energizes status light.
• Timer counts down and digital display indicates remaining time. Can be deactivated for
continuous operation.
• Additionally, unit will display total accumulated running time for service information.
AMBIENT OPERATING ENVIRONMENT
0
° - 40°C, 90% humidity, non-condensing
SELF-DIAGNOSTIC STATUS
Warning signal (audible and visible) indicates when shaking speed deviates more than 5
RPM or the temperature deviates more than 1.0
°C from setpoint and when timer operation
has expired. The audible alarm can be deactivated/activated by the operator.
REMOTE MONITORING
• Chart recorder outputs for speed and temperature (0-5V).
• 1V per 100 RPM; 1V per 20°C, accuracy ± 25mV.
