14. Reinstall the two 5/16 inch hex nuts and tighten.
15. Tighten the two heat sink mounting screws.
16. Reconnect the harness wiring to connectors J1 and J2. Make sure that each

connector is properly positioned (keys mate and no pins remain exposed).

17. Reinstall the temperature control board:

a. Snap the temperature control board onto the main control board, making sure

the board-to-board connectors mate properly.

b. Reinstall one ¼ inch screw and the temperature sensor ground lug at the corner

near J103. Reinstall the two remaining ¼ inch screws and nylon flat washers.

c. Reconnect the harness wiring to connectors J101, J102, J103 and J104. Make

sure that each connector is properly positioned (keys mate and no pins remain
exposed).

18. Reinstall the front panel and secure with the five screws.
19. Connect the power cord to the rear of the shaker.

5.12

Replacing the Temperature Control Board

1. Switch the shaker OFF and disconnect the power cord.
2. Remove the five screws that hold the front panel (two screws on the side and three

on the bottom); allow the front panel to lie down on its face.

3. Disconnect the harness wiring from connectors J101, J102, J103 and J104 (see

Figure 14 above).

4. Remove the three ¼ inch screws, the two nylon flat washers and the temperature

sensor ground lug.

5. Disconnect the temperature control board from the main control board, being

careful not to damage the board-to-board connectors. Apply force perpendicular to
the plane of the board. Do not lift from one end.

6. Snap the new temperature control board onto the main control board, making sure

the board-to-board connectors mate properly.

7. Reinstall one ¼ inch screw and the temperature sensor ground lug at the corner

near J103. Reinstall the two remaining ¼ inch screws and nylon flat washers.

8. Reconnect the harness wiring to connectors J101, J102, J103 and J104. Make sure

that each connector is properly positioned (keys mate and no pins remain exposed).

9. Replace the front panel and secure with the five screws.
10. Connect the power cord to the rear of the shaker.
