Eppendorf 3100 Digital Water Bath Shake - Manual (Page 21)

15
Innova 3100  M1231-0050 Operating manual
Figure 7: Platform Installation
3.3.4 Electrical Connections
1. If you have not already done so, check the voltage selector switch at the
rear of the unit to be sure that it is set to the appropriate voltage.
2. Remove the caution label from the rear of the unit.
3. Set the circuit breaker on the right side of the unit to the OFF position.
4. Make sure there is enough space around the mains/power connections to
unplug the device.
ONLY THEN:
4. Connect the adequately rated power cord to the power cord connection and
to a grounded electrical outlet.
CAUTION!
Be sure to use the following checklist BEFORE making
electrical connections.
CAUTION!
A grounded electrical outlet is necessary for the safe
operation of this instrument.
