ADVANCE ADAPTERS INC. P/N: 50-9001
P.O. Box 247, 4320 Aerotech Center Way New Item: (9/09)
Paso Robles, CA 93447 PAGE
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date:
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a
service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
1. 1 51-9000 ADAPTER PLATE
2. 1 52-9001 SPUD SHAFT 29 SPLINE
3. 1 716064 SHIM
4. 1 716064B LOCK WASHER
5. 1 716239 THRUST WASHER
6. 1 716302 SEALED BEARING
7. 1 716310 SEALED BEARING
8. 1 716762 SEAL
9. 1 300922 90 DEGREE BARBED FITTING
10. 6 302069 STUD BOLT 2-3/16" OAL 3/8-16,24
11. 6 302071 FLANGE NUT 3/8-24 PLATED
12. 2 340031 DOWEL PIN
13. 2 723103 LOCK WASHER 5/16" PLATED
14. 2 723118 H.H.C.S. 5/16"-18x1-3/4" LG
15. 2 723101 NUT 5/16"-18 PLATED
16. 6 723704 LOCK WASHER 3/8" PLATED
17. 6 723723 H.H.C.S. 3/8"-16x1-1/2"
18. 1 728701 NYLON LOCK NUT
KIT CONSISTS OF:
No.
Qty Part No. Description
1 OF 6
LAND ROVER SERIES T-CASE to NP
CIRCULAR 6 ADAPTER with DODGE 29 SPLINE
03-25-10
