Special Note: The components packaged in this kit have been assembled and machined for specific types of conversions. Modifications to any of
the components will void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required
to complete your conversion, we strongly recommend that you contact our sales department for more information. This instruction sheet is only
to be used for the assembly of Advance Adapter components. We recommend that a service manual pertaining to your vehicle be obtained for
specific torque values, wiring diagrams and other related equipment. These manuals can be found online, at dealerships and parts stores.
AX15 TO AMC JEEP ADAPTER
Remove the stock engine and bellhousing assembly,
the bellhousing from the transmission and the front
bearing retainer.
Clean both surface areas of silicone or gasket debris.
The new adapter plate indexes on the transmission
using the transmission front bearing.
The two transmission dowel pins are not used. There
are two oversized holes in the adapter to clear these
dowel pins.
Using a disc grinder (wearing the necessary safety
glasses), grind the necessary clearance for the bolt
heads. Test fit.
Install the new seal ( P/N 716742) into the
711543 adapter plate.
INSTALLATION PROCEDURES:
