Chapter 4 – Safety Devices
18 TB80/TB85J – 0112622EE
The light flashes at about one flash per second when the
engine is running.
Driving Lights
Optional headlights and blinking tail lights may be in-
stalled on the machine. The headlights are located on
the top of the front cowling. The tail lights are mounted on
the sides of the rear cowling.
Driving lights help improve visibility while driving the aerial
platform and help others see it too. Driving lights are not
for driving on public roadways.
Platform Work Lights
Optional platform work lights may be located on the top
rail of the platform (refer to Figure 4.10), one on each side
of the upper control panel.
Figure 4.10 – Platform Work Light
Use the platform lights to improve visibility while working
aloft in dimly lit areas. Do not use the platform work lights
to drive on public roadways.
If the engine oil pressure falls below a safe operating value
the engine will shut off. The engine can be restarted with
low oil pressure, but it will only run a few seconds before
it shuts off again.
Horn
The horn may be used to warn personnel on the ground.
The horn button is on the right side of the upper control
panel (refer to Figure 4.8). The horn is operational when
the machine is set up for operation from the upper con-
trols.
Figure 4.8 – Right Side of Upper Control Panel
Drive Motion Alarm
An optional drive motion alarm may be provided on the
machine. When the drive/steer control is moved out of
neutral the alarm sounds, in short beeps, to warn per-
sonnel in the work area to stand clear.
Flashing Light
An optional red or amber flashing light may be located on
the top of the boom near the base end (refer to Figure
4.9). The flashing light warns personnel that the aerial
platform is in the area.
Figure 4.9 – Flashing Light
Horn Button
Flashing Light
