Chapter 2 – Specifications
8 TB80/TB85J – 0112622EE
General Specifications – TB85J
Aerial Platform
Working height 27.8 m (91 ′ 3″)
Maximum platform height 26.0 m (85 ′ 3″)
Horizontal reach 23.5 m (77 ′)
Main boom
Articulation -13.5° to +70°
Extension 12.1 m (40 ′) approx.
Turntable rotation 360° continuous
Turning radius, inside
Axles extended 5.3 m (17 ′ 5″)
Wheelbase 3.6 m (12 ′)
Ground clearance 33 cm (13 ″)
Maximum wheel load 6,985 kg (15,400 lbs)
Maximum ground pressure 5.9 kg/cm² (84 psi)
Weight, EVW
Approximate 13,680 kg (30,160 lbs)
Width
Axles retracted 2.5 m (8 ′ 6″)
Axles extended 3.9 m (12 ′ 10″)
Stowed length 11.2 m (36 ′ 10″)
Stowed height 2.9 m (9 ′ 7″)
Platform
Dimensions
Standard Aluminum 76 cm x 243 cm (30 ″ x 96″)
Rated work load
Aluminum 76 cm x 243 cm (30 ″ x 96″) 272 kg (500 lb)
Rotation 170 degrees
Maximum number of occupants 2 people
Optional AC generator 220 V
Function Speed
Turntable rotation
Booms retracted 168 seconds minimum
Booms extended 228 seconds minimum
Main boom
Up
Booms retracted 80 seconds minimum
Booms extended 105 seconds minimum
Down
Booms retracted 80 seconds minimum
Booms extended 105 seconds minimum
Extend 80 to 90 seconds
Retract 60 to 70 seconds
Jib
Up 25 to 35 seconds
Down 25 to 35 seconds
Platform rotation 16 to 20 seconds
Drive – four wheel drive
High 4.8 km/h (3.0 mph)
Mid 2.4 km/h (1.5 mph)
Low 1.2 km/h (0.75 mph)
Drive – two wheel drive
High 4.8 km/h (3.0 mph)
Low 1.2 km/h (0.75 mph)
Drive System
Standard Four wheel drive
Gradeability 30%
Optional Two wheel drive
Gradeability 25%
Tires
Foam filled 38 cm x 50 cm (15 ″ x 22.5″), 16 ply
Electrical System
Voltage 12 V DC negative chassis ground
Source Two - 12 V 550 CCA batteries
Fluid recommended distilled water
Hydraulic System
Maximum pressure 19,305 kPa (2,800 psi)
Reservoir capacity 151 l (40 US gal)
System capacity 246 l (65 US gal)
Maximum operating temperature 93°C (200°F)
Hydraulic fluid recommended
Above -13°C (10°F) Mobil DTE-13M (ISO VG32)
Below -13°C (10°F) Mobil DTE-11M (ISO VG15)
Engine
Diesel Cummins B3.3
Diesel Deutz F4L-2011F
Fuel Tank Capacity
Diesel 204 l (54 US gal)
Ambient Air Temperature Operating Range
Celsius -18°C to 43°C
Fahrenheit 0°F to 110°F
Maximum Wind Speed
Gust or steady 45 km/h (28 mph)
