Pay particular attention to the chassis welds
Figures 7.17 - Boom Welds
Closely inspect boom welds all the way around, for
cracks.
■
Lanyard Anchor Points
Figure 7.18 - Lanyard Anchor Points
Visually check the lanyard anchor points to see that
they are not deformed or cut off.
■
Platform Gravity Gate
Figure 7.19 - Platform Gravity Gate
■
Platform Guardrails
Figure 7.20 - Platform Guardrails
Visually inspect the platform guardrails to see that
none of the tubing has been cut out, removed, or
deformed in any way.
Visually check the guardrail welds to see that none
is cracked nor ground down.
■
Flashing Light (option)
Figure 7.21 - Flashing Light
Visually check the optional flashing light, to see that
the light flashes at approximately one flash per sec-
ond when the motor key switch is turned on.
MHP12/34J – 11447A
page 7 - 5
7. Daily Inspection and Maintenance
