❑ RCD/ELCB AC outlet
Figure 2.8 - RCD/ELCB AC Outlet
The RCD (Residual Current Device) is located at
the base and will protect against short circuits to
earth. When there is a short circuit the RCD will
shut down the 230v AC power to the platform outlet.
To reset the outlet disconnect the power tool lead
from the platform box and reset the RCD at the
base.
If the problem persists call a trained service techni-
cian.
❑ Flashing light
Figure 2.9 - Flashing Light
The flashing light aler ts people that the
MHP12/34J is moving. The light flashes at about
one flash per second any time the MASTER KEY
switch is on. There is no ON/OFF switch for the
flashing light, it cannot be turned off while the
MHP12/34J is running.
MHP12/34J – 11447A page 2 - 3
2. Safety Devices
RCD
Power Input
Connector
Power Outlet
At Platform
