43
3 Swivel
Raceways
2-Front
Casters
MPG-Pressure
Gun
√
4 Mast Chains 2-Per Mast
Section
CL-Brush or
Spray √
Inspect,
lubricate if
dry or rusting.
Key to Lubricants: MPG- Multipurpose Grease
HO- Hydraulic Oil – ISO-Vg grade 32, 46.
CL- Chain Lube. Use a good quality chain lubricant
Notes: (a) Be certain to lubricate like items on each side of the machine.
(b) Recommended lubricating intervals are based on normal use. If machine is subjected
to severe operating conditions, such as a high number of cycles, location, corrosive/dirty
environment, etc., user must adjust lubricating requirements accordingly.
(c) Prior to checking hydraulic oil level, operate machine through one complete cycle of lift
function (full up and down). Failure to do so will result in incorrect oil level reading on the hydraulic
reservoir.
