21
Figure 2-1. Daily Walk-Around Inspection for SPM20 Machines.
1. Drive and Caster Wheels
2. Base Frame
3. Manual Descent Control Valve
4. Motor/Pump/Reservoir Unit
5. Batteries (Open Cover Doors)
6. Platform Assembly
7. Platform Control Console
8. Ground Control Console
9. Mast Assembly
2.5 FUNCTION CHECK
Once the “Walk-Around” Inspection is complete, perform a function check of all systems in
an area free of overhead and ground level obstructions. Refer to Section 3 for more specific
operating instructions.
WARNING
IF THE MACHINE DOES NOT OPERATE PROPERLY, TURN OFF THE MACHINE
IMMEDIATELY!
REPORT THE PROBLEM TO THE PROPER MAINTENANCE PERSONNEL. DO NOT
OPERATE THE MACHINE UNTIL IT IS DECLARED SAFE FOR OPERATION.
Perform a Function Check as follows:
1. From the ground controls with no load in the platform:
a. Operate ground control functions, platform lift up and lift down.
