37
SECTION 5. GENERAL SPECIFICATIONS AND OPERATOR
MAINTENANCE
5.1 INTRODUCTION
This section of the manual provides additional necessary information to the operator for
proper operation and maintenance of this machine.
The maintenance portion of this section is intended as information to assist the machine operator to
perform daily maintenance tasks only, and does not replace the more thorough Preventive
Maintenance and Inspection Schedule included in the Service and Maintenance Manual.
Other Publications Available Specific to this Machine:
Service and Maintenance Manual
Illustrated Parts Manual
5.2 GENERAL SPECIFICATIONS
Machine Specifications
SPECIFICATION SPM20
Gross Machine Weight (Platform
Empty):
1050kg
Machine Height (Platform Stowed): 2100mm
Maximum Ground Bearing
Pressure: (per wheel)
360kg
Maximum Operating Incline: 1.0°
Maximum Travel Grade (Grade
ability): (Platform STOWED ONLY)
15-20%
Maximum Travel Grade (Side
Slope): (Platform STOWED ONLY)
5°
Maximum Drive Speeds (Operator
Variable):
1.1- 4.0 km/h
Maximum Base – Overall: (Width x
Length)
76cm x 136cm
Maximum Wind Speed: 0 km/h-Machine rated for indoor use only
Maximum Horizontal Manual Side
Force: 200 N
Maximum Hydraulic System
Pressure: (Recommended initial
setting)
12MPa
Hydraulic Reservoir Capacity: 5L
