Snorkel SPM20-sn00000 User Manual
Page 31
27
Emergency Stop/Shut Down Button
POWER OFF
PUSH IN-To Engage
Emergency Stop
POWER ON
TURN CLOCKWISE and RELEASE-To Reset
Emergency Stop
Platform Up Platform Down
TURN UP Left Toggle Switch, TURN UP Left Toggle Switch,
And TURN UP Right Toggle Switch And TURN DOWN Right Toggle Switch
Toggle Switch Toggle Switch
Manual Descent Control Valve
DRAW-OUT TO LOWER Platform RELEASE TO
–STOP Platform Descent
