41
* 1 MPa = 10 bar
** Necessary volume of hydraulic fl uid in the hydraulic unit to operate the unit
(differential volume on piston / rod side)
type SP 512
ref. no. 111040000
81-10-40
(171040000)
min. spreading force
(25mm / 0.98in. from the tips)
[kN] 84
[lbf.] 18900
max. spreading force
(25mm / 0.98in. from the tips)
[kN] 120
[lbf.] 26977
spreading force HSF
(according to NFPA)
[kN] 108
[lbf.] 24279
spreading force LSF
(according to NFPA)
[kN] 77
[lbf.] 17310
max. spreading distance
[mm] 610
[in.] 24.0
max. pulling force (on mounting
borehole for chain set)
[kN] 98
[lbf.] 22031
pulling distance (on mounting
borehole for chain set)
[mm] 437
[in.] 17.2
pulling force HPF
(according to NFPA)
[kN] 67
[lbf.] 15062
pulling force LPF
(according to NFPA)
[kN] 49
[lbf.] 11016
dimensions
l x w x h
[mm] 784 x 380 x 216
[in.] 31.87 x 14.96 x 8.50
weight incl. hydraulic fl uid
[kg] 26,4
[lbs.] 58.2
max. operating pressure
[Mpa] * 70
[psi.] 10000
min. needed volume
of hydraulic fl uid
[l] ** 0,34
[gal.-
US]
0.09
coupling system Steckkupplung Monokupplung
classifi cation acc. to DIN EN 13204 CS 84/610-26
