Page 10
10
4.2 Unit in detail
Quick-disconnect coupling
system:
14
13
1
2
3
4
5
6
7a
8
9
10
11
12
6
8
7b
6
6
5
3
1
2
11
12
9
10
1 Star grip
2 Control valve
3 Spreader body
4 Handle
5 Hand guard
6 Spreading arm
7a Multifunction tip incl. peeling
function with borehole for chain set
7b Diamond-tip with borehole for chain
set
8 Roll pin
9 Pressure hose
10 Return hose
11 Handhold
12 Mono-coupling male
13 Quick-disconnect coupling (male)
14 Quick-disconnect coupling (female)
