40
* 1 MPa = 10 bar
** Necessary volume of hydraulic fl uid in the hydraulic unit to operate the unit
(differential volume on piston / rod side)
type SP 510
ref. no. 111030000
81-10-30
(171030000)
min. spreading force
(25mm / 0.98in. from the tips)
[kN] 62
[lbf.] 13900
max. spreading force
(25mm / 0.98in. from the tips)
[kN] 230
[lbf.] 51706
spreading force HSF
(according to NFPA)
[kN] 79,9
[lbf.] 17962
spreading force LSF
(according to NFPA)
[kN] 54,6
[lbf.] 12275
max. spreading distance
[mm] 800
[in.] 31.50
max. pulling force (on mounting
borehole for chain set)
[kN] 55
[lbf.] 12365
pulling distance (on mounting
borehole for chain set)
[mm] 665
[in.] 26.18
pulling force HPF
(according to NFPA)
[kN] 44,4
[lbf.] 9982
pulling force LPF
(according to NFPA)
[kN] 31,1
[lbf.] 6992
dimensions
l x w x h
[mm] 900 x 380 x 215
[in.] 35.43 x 14.96 x 8.46
weight incl. hydraulic fl uid
[kg] 25
[lbs.] 55.1
max. operating pressure
[Mpa] * 70
[psi.] 10000
min. needed volume
of hydraulic fl uid
[l] ** 0,43
[gal.-
US]
0.12
coupling system Steckkupplung Monokupplung
classifi cation acc. to DIN EN 13204 BS 62/800-25
