Lukas LSI Series Cutter User Manual
Cutter series lsi, Operating instructions recycling system

Cutter Series LSI
84150/1362-85 GB
Issue 12.2005
Replaces 6.2004
Operating Instructions
Recycling System
8 2
3
9
1
7
6
5
4
11
10
1
Control valve with star shape ring
2 Quick-connect socket StMu 61 - 0
3 Quick-connect plug StNi 61 - D
4 Cutter blades, resp. blade arm
5
Central bolt with selfl ocking nut
6
Protecting hose
7 Hydraulic cylinder
8 Hose, red: Pressure
9 Hose, blue: Return
10 Handle
11 Handle
