38) Bolt the housing in place. Install the 2 set screws into the forks using
Loctite (Fig.37,37a). You will need to verify shaft end play at this point.
End play should be 0.003”-0.006” on the front output shaft. If new
bearings were installed, you may need to adjust the shim pack noted in step
35. Once proper end play is verified, remove the bearing plate installed in
step 35, apply a seal with RTV and reinstall. Install the front output shaft
seal (available with the optional Seal & Gasket Kit), yoke, and nut. Torque
to 100 lb.ft..
Fig.37 Fig.37a.
39) Install the needle bearings into the idler gear using a thick grease (Fig.38).
Remember to install the three steel rings along with the needle bearings.
Be sure that all needle bearings are installed.
Fig.38
