JB Conversions 2307 LoMax 300 User Manual
Page 13
26)
Roll the 1
st
rail 90 degrees in a clockwise rotation (Fig.25). You should not
feel the ball detent pop into place until you tap the 1
st
rail rearward a bit
after it is rotated.
Fig.25
27)
Tap the 1
st
rail rearward 1 more notch to the position shown. Both rails
should now be at equal lenth from the rear face of the aluminum housing.
Leave them in this position for further assembly of the tcase (Fig.26).
Fig.26
