JB Conversions 2307 LoMax 300 - Manual (Page 15)

30) Reposition the case in the vertical press to allow the new slider ring and 18
tooth LoMax helical gear to be placed on the front output shaft with a
tapered roller bearing # 86649. Press the bearing onto the shaft until it
stops at the shaft shoulder (Fig.29). Verify the 18 tooth helical gear can
turn free after the press operation is completed. Do not press against the
cage of the bearing.
Fig.29
31) Place the remaining slider ring onto the clutch teeth of the rear output
shaft. Install the input gear cluster into the front of the case followed by
the 6 allen or torx screws (Fig.30). Use RTV to seal the aluminum input
housing.
Fig.30
32) Place the original rear bearing shims onto the rear output shaft in their
original location (Fig.31).
Fig.31
