JB Conversions 2307 LoMax 300 - Manual (Page 16)

33) Bolt the rear bearing housing onto the case followed by the tapered roller
bearing #15117 (Fig.32). Install the rear output yoke and seal (available
with the optional Seal & Gasket Kit). Torque to 100 lb-ft. Verify end play at
0.002”-0.005”. The installation of the LoMax gears does not affect shaft
end play however if new bearings are being installed, end play may be
effected. If end play is incorrect for any reason, remove the rear bearing
housing and reshim the bearing.
Fig.32
34) Place the bearing cup #M86610 into the rear bore of the case (Fig.33).
Fig.33
