Product manual – Class1 119327 - VDR system 118093 118097 118551 118620 119375 - EXTERNAL User Manual
Page 26
FORM-ENG-0018 REV A 05-27-03
607 NW 27th Ave
Ocala, FL 34475
Ph: 352-629-5020 or 1-800-533-3569
Fax : 352-629-290 or 1-800-520-3473
PRODUCT MANUAL
PAGE
25
OF 26
DATE
10/17/2011
PRODUCT GROUP
ES-Key
P/N
119914, 118093, 118620, 118551, 119375
REV
1.70
PRODUCT
Vehicle Data Recorder and Seat Belt Warning system
BY
AMS
10.4. Vehicle Data Recorder (p/n 119914)
Product category
SAE J1939 CAN
Voltage range
+9VDC…+32VDC
Current draw (@ 13.8VDC)
78mA
Temperature range
-40ºC…+85ºC
Environmental range
IP 42
CAN specification
SAE J1939, 250 Kbits/second
Protection
Internal thermal fuse
Reverse voltage protection (pins 1 and 12 of connector)
CAN buses protected to 24V
ESD voltage protected to SAE J1113 specification for heavy duty trucks
Transient voltage protected to SAE J1113 specification for heavy duty trucks
