PRODUCT GROUP ES-Key P/N 119914, 118093, 118620, 118551, 119375 REV 1.70
PRODUCT Vehicle Data Recorder and Seat Belt Warning system BY AMS
10. Operating Parameters
10.1. Seat Belt Warning input module (p/n 118093)
Product category SAE J1939 CAN
Voltage range +9VDC…+32VDC
Current draw (@ 13.8VDC)
32mA (no inputs active)
34mA (2 inputs active)
37mA (4 inputs active)
40mA (6 inputs active)
42mA (8 inputs active)
44mA (10 inputs active)
47mA (12 inputs active)
50mA (14 inputs active)
53mA (16 inputs active)
55mA (18 inputs active)
57mA (all inputs active)
Temperature range -40ºC…+85ºC
Environmental range IP 67
CAN specification SAE J1939, 250 Kbits/second
Protection
Internal thermal fuse
Reverse voltage protection (pins 1 and 12 of gray connector)
CAN buses protected to 24V
ESD voltage protected to SAE J1113 specification for heavy duty trucks
Transient voltage protected to SAE J1113 specification for heavy duty trucks
10.2. Seat Belt Warning display (small – p/n 118620)
Product category SAE J1939 CAN
Voltage range +9VDC…+16VDC
Current draw (@ 13.8VDC) 57mA
Temperature range -40ºC…+85ºC
Environmental range IP 10
CAN specification SAE J1939, 250 Kbits/second
Protection
Internal thermal fuse
Reverse voltage protection (pins 1 and 2 of connector)
CAN buses protected to 24V
ESD voltage protected to SAE J1113 specification for heavy duty trucks
10.3. Seat Belt Warning display (large – p/n 118551, p/n 119375)
Product category SAE J1939 CAN
Voltage range +9VDC…+32VDC
Current draw (@ 13.8VDC)
25mA (no seat LEDs active)
75mA (all green seat LEDs active)
Temperature range -40ºC…+85ºC
Environmental range IP 42
CAN specification SAE J1939, 250 Kbits/second
Protection
Internal thermal fuse
Reverse voltage protection (pins 1 and 2 of connector)
CAN buses protected to 24V
ESD voltage protected to SAE J1113 specification for heavy duty trucks
Transient voltage protected to SAE J1113 specification for heavy duty trucks
