Operation manual, Installation, Cutout dimensions – Class1 114356 - ITL 4LT with 1-wire and CAN COM 113739 114378 User Manual
Page 13: Outer bezel dimensions
FORM-ENG-0018 REV A 05-27-03
PAGE
12 of 22
S U I T A B L E F O R E X T E R N A L D I S T R I B U T I O N
OPERATION MANUAL
DATE
10/23/2007
PRODUCT GROUP
ITL
P/N
12V: 113739 ; 24V: 114378
REV
1.20
607 NW 27th Ave
Ocala, FL 34475
Ph: 352-629-5020 or 1-800-533-3569
Fax : 352-629-2902 or 1-800-520-3473
PRODUCT
4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN
BY
AMS
DATASHEET
P/N:114356 -
UNCONTROLLED
IN
PRINTED
FORMAT
-
P
RINTED
:
10/24/07
6. Installation
6.1. Cutout
dimensions
The display requires a cutout as shown. The display is water tight and may be mounted in any location on the
operator’s panel.
Unit of scale: inches [millimeters]
6.2. Outer bezel dimensions
Unit of scale: inches [millimeters]
