Caterpillar 3126 ecm – Class1 Vernier Throttle for CAT User Manual
Page 8
8
DOC 101058C_c:\manuals\throttles\cat\catthrot.p65
Caterpillar Interface
C2-B
Throttle Signal
C1-A
12 VDC
C3
C1-B
Sensor Common
(Ground)
Sensor Common
+8 VDC
Throttle Position
CAB Throttle
Throtle Position
Remote Throttle
Switch
(PTO Engaged)
Relay
PTO Lamp
K998 Blue
C986 Brown
C985 Blue
C993 Brown
K999 Green
Caterpillar ECM 3126
8
PTO On/Off
29 Sensor Common
Ground
35 8 VDC
37 TPS Input
21 Output #1
PTO On Lamp
Caterpillar ECM 3126
12 VDC
87a
87
85
86
30
PTO
FAST
IDLE
OEM
Interlocks
Fast Idle
Switch
HIGH IDLE POT (10K)
VERNIER CONTROL (10K)
Caterpillar 3126 ECM
Wiring the Class1 Vernier Throttle Interface with a fast idle option
Manuals\Throttles\catvthi.ai..120996
C2-A
C2-C
C4
3126
