Hi-idle – Class1 Vernier Throttle for CAT User Manual
Page 6
6
DOC 101058C_c:\manuals\throttles\cat\catthrot.p65
HI-Idle
Class 1
CAT Interface
C2-A Throttle Ground
C2-B Throttle Signal
C2-C Throttle Source
C1-A
12 VDC
12 VDC
FAST
IDLE
OEM
Interlocks
Fast Idle
Switch
HIGH IDLE POT
C4
manuals\throttles\cat\cathigh.ai..110298
Wiring the Class1 Vernier Throttle with high idle option only
