Page 10
10
DOC 101058C_c:\manuals\throttles\cat\catthrot.p65
3126B HEUI
Class 1
Caterpillar Interface
C1-A 12 VDC
C3
C1-B
Sensor Common
(Ground)
Throtle Position
PWM Out
PTO Engaged
PTO Lamp
56 PTO On/Off
Ground
3 Input Sensor
Common #2
Ground
68 INPUT #8
RAPS PWM
30 Output #1
PTO On Lamp
Ground
New Caterpillar 3126B
12 VDC
Caterpillar 3126B ECM
Throttle Interface Module
manuals\throttle\cat\3126B-HI.AI....102398
1
2
3
4
5
6
7
12
CAT J1/P1 Connector
ECM RIGHT SIDE
Vehaicle Harness Connector
ECM Side
Relay
87a
87
85
86
30
Programming Considerations
Parameter Available CAT Default
Program
PTO
Remote Throttle Off
ON
PTO Top Engine Limit
600-2120 2120
2120
PTO RPM set speed
Idle-PTO TEL 0 RPM
xx
PTO Cab Throttle RPM TEL, Idle,PTO TEL TEL
TEL
PTO activates cooling fan Normal, Continuous Normal
Continuous
Torque Limit 200 lb-ft to Rated 2000 lb-ft
Rated
Idle PTO vehicle speed limit 1 to 15 MPH 1 MPH
Max
8
9
10
11
13
14
24
32
40
48
23
31
39
47
57
70 69 68 67 66 65 64 63 62 61 60 59 58
C2-A Ground
C2-C +5VDC
C2-B Throt Sig
C4
IdleValidation
Override
PTO
FAST
IDLE
OEM
Interlocks
Fast Idle
Switch
HIGH IDLE POT (10K)
VERNIER CONTROL (10K)
