Sample circuits – Class1 ESM3 User Manual
Page 12
12
105519 08172000
TB#1
TB#9
TB#5
TB#13
TB#3
TB#11
TB#7
TB#15
TB#2
TB#10
TB#6
TB#14
TB#4
TB#12
TB#8
Signal From Brake Lights
OEM Fast
Idle Circuit
PSI Switch closed
when Park Brake set
Ignition
Ground
Shed Enable
Relay
Fast Idle
Switch
OEM Fast Idle
Interlocks
Relay
Automatic FAST IDLE CIRCUIT, disabled when service brake is applied
SAMPLE CIRCUITS
